110cc Engine Motor ATV Go Kart Auto fit 90cc 70cc 50cc Quad Four Wheeler Go Cart

110cc Engine Motor ATV Go Kart Auto fit 90cc 70cc 50cc Quad Four Wheeler Go Cart

110cc Engine Motor for ATV Go Kart Auto

110cc Engine Auto ATV Go Kart Fit 50cc 90cc 70ccDescriptionCondition: Brand New
Engine Type: Single Cylinder, 4-Stroke, 2-Valve, Air Cooled
Horsepower(KW/Rpm):  5.0/8000
Max. Torque(N?m/Rpm): 6.9/6500
Min. Fuel Consumption(g/Kw.h):367
Bore*Stroke: 52.4mmX49.5mm
Displacement(cc): 107
Compression Ratio: 9.0:1
Ignition: CDI
Lubrication: Pressure/Splash
Starter: Electric Starter
Transmission:Auto Transmission
Carburetor Model: PZ19
Oil capacity(ml): 900Engine automatic 110cc fits most Chinese made ATV Go Kart 50cc 70cc 90cc 110cc since the mounting holes are same, do not install if your engine with starter bottom mounted since the mounting holes are not same.It is forward only. It is good idea if you like to either replace your old engine or upgrade your ATV or Go kart to be faster or more powerful.?This engine assembly comes with Intake Pipe, Drive Sprocket, Sprocket cover & Spark Plug, but doesn't come with Carburetor, Battery, CDI, Voltage Regulator, Ignition Coil, Starter Relay, Air Filter, Gas Tank, Main Wire Harness Assembly, Switch Assembly, Throttle Cable, etc.

Crank Shaft: The engine is low speed with high torque and has large diameter bearings for crankshaft connecting rod, increasing the reliability of the bearings.2.

Air-cooled Engine: There are metal fins covering the outside of the cylinders and the heat generated by the engine is released directly into the air when the cooling fan blows air over fins. It has the advantages of simple structure, light weight, wide adaptability to climate change, rapid start up and no need of radiator.3. High-flow Oil Pump: Reduces the wear of friction pairs and prolongs the engine service life.4. Lubricating Oil Strainer: Helps removing solid contamination from lubricating oil, largely reducing the wear of friction pairs and prolonging the engine service life.5.

Aluminum Cylinder Head and Iron Cylinder Body : Improves the heat dissipation capability, cuts the weight and increases the torque of the engine. Packing The quality engine system production complies with the requirements of ISO 9001:2000. All the engines have passed the 200-hour enhanced durability bench test and the 20000 km road test. The engine has the similar performance, facility and reliability as many brand engines, such as Honda, Yamaha, Kawasaki and so on. It also obtained the DOC authorization. All engines have the identification, gears and oil labels.

Material: Built with high quality aluminum cylinder head and aluminum cylinder body Transportation: The best way to transport this engine - the oil in the engine should be released and repackaged to avoid leaking. Also package the engines with five-layer anti-earthquake carton boxes to ensure the items arrive in perfect condition to their destination.

Usage Tips: Do start the engine in an open place to let the exhaust gas gets full emission.

For Automatic Transmission Engines, don't start it at reverse. For Semi-auto and Manual Transmission Engines, do start at Neutral.3. Check lubricating oil level and fuel level regularly. Make sure they are sufficient and not leaked.4. Do not accelerate until it has warmed up for 1-3 minutes if cooler start engine.5. All new engines need a initial run-in time. Because the surface of the parts is not that smooth, they need a time to run-in to have the parts get smooth and work together better. The initial run-in should be at least 500KM. During the initial run-in, avoid full-open throttle and don't start it over 80 percent of the top speed. Make sure to clear all fuel and change new when initial run-in over. Be strictly obey this will prolong the engine service life and has it working in good condition.
